| Quantity: | |
|---|---|
Specifications | |
Device model | Parameter Description |
Pressure range | 2-53KN |
Drive System | Lndustrial Computer + Sports Card Control |
C-type throat depth | 600mm |
C type throat height | 400mm |
Sravel distance | 200mm |
Equipment load Repeatability | ±1% |
Sower | 7.5KW |
Voltage | 380V Three-Phase Four-Wire 50HZ |
Security system | Standard |
Automatic feeding Control System | Two Feeders |
Automatic Feeding Tool | Optional |
The Load Resides Salculator | Standard |
Positive Limit | Standard |
Bulk Leak Prevention System | Standard |
Hand Operated Tools | Standard |
Weight | 765KG |
Dimensions | 1100*1100*2100mm |
Intelligent and Efficient
Intelligent control
Autonomic regulation
Precision calculation
Modular Autofeed System.
Double disc automatic feeding
Servo touch screen
Wireless connections
Remote upgrade
Introduce
1. It is suitable for riveting carbon steel plates with nuts M10 and below, nut posts below M8, and screws below M6; it can realize flange extraction, convex hull forming, rivet-less connection, self-piercing riveting and other processes
2. Output and input points are reserved for later function upgrades, you only need to re-enter the program without changing the electric control board
3. Satisfied with more than 95% of plate riveting
4. Strong avoidance space makes it easier to unload bending products
5. According to the height of the product, the rising position can be reasonably adjusted to save riveting time
6. The dedicated pressure test adjustment button allows you to find the correct riveting pressure within 10 seconds, and the equipment load accuracy is ±1%.
7. Hydraulic systems can save more than 70% of energy; compared with pneumatic solutions, they can save up to 90% of costs.
8. According to the conductive performance of the product, it adopts conductive and non-conductive modes to work, which greatly improves the operator's confidence and riveting efficiency, and there is no potential safety hazard.
9. It is suitable for M2～M6 PEM series screws/nut standoffs and nuts, which improves the riveting efficiency of manual feeding by three times and enables you to automatically divert import and transport various rivets without changing the vibrating plate.
10. quick interchangeable
11. The maximum pressure holding time can reach more than 6S, reducing the deformation of the plate
12. Effectively prevent soft materials such as aluminum, copper, and materials with a thickness below 1.0mm, which are surface sprayed or unique surface treated and then riveted, deformed, or scratched.
13. The number is set according to the number of riveting times required for a single part. Every time the machine tool works, the counter counts once. After reaching the set number, it automatically resets to zero and restarts counting. At the same time, the buzzer alarm prompts to prevent the phenomenon of missing riveting.
Application features
Servo Fastener Insertion Machine is an efficient and accurate automated equipment designed for the installation of all kinds of fasteners. With its advanced servo control technology, the machine is able to realize fast and accurate fastening process, which is widely used in many industries such as automotive, electronics, home appliances, machinery manufacturing and aerospace.
Main Features
High precision: servo control system ensures that the installation torque of each fastener reaches the preset standard, significantly improving product quality.
High efficiency: The fast insertion speed significantly shortens the production cycle and improves the overall efficiency of the production line.
Traceability: The system records the parameters of each fastening process, which is convenient for subsequent quality inspection and tracking.
Intelligent operation: Friendly operation interface simplifies equipment setup and adjustment, suitable for various production needs.
Application Areas
Automobile manufacturing: for the fastening of body, chassis and engine components to meet the requirements of high strength and high precision.
Electronic products: in circuit board and shell assembly, to ensure the accurate installation of screws.
Home appliance industry: applied to the installation of internal components of refrigerators, washing machines and other household appliances to enhance production efficiency.
Machinery Manufacturing: Provide fast and accurate fastening solutions for all types of mechanical equipment.
Aerospace: precise installation of key components to ensure the safety and reliability of equipment.
